To align the partitions on XtremIO volumes after an upgrade from Windows Server 2003 to Windows Server 2008, the following steps should be taken:

Backup the Data: First, ensure that all data on the existing misaligned partitions is backed up to a secure location to prevent any data loss.

Run Diskpart: Use the Diskpart utility, which is a command-line tool in Windows, to delete the existing partitions and create new aligned partitions. Diskpart allows for more control over the alignment process compared to graphical tools.

Recreate the Partition: After deleting the misaligned partitions, create new partitions using Diskpart with the correct alignment settings as per the XtremIO best practices.

Restore the Data: Once the new partitions are created and properly aligned, restore the data from the backup to the newly aligned partitions.

This process ensures that the partitions are aligned correctly, which can significantly improve performance due to more efficient disk access patterns1. It's important to follow the detailed procedures outlined in the official Dell XtremIO Deploy Achievement documentation to ensure proper alignment and to avoid any potential issues during the process.

For a VMware VM running on vSphere 6.5 that will reside on a datastore provisioned from an XtremIO volume, the disk should be presented to the guest as Thick Provisioned, Eager Zero (EZT). This is recommended for the best performance and efficient capacity usage.

Thick Provisioning, Eager Zero: This type of provisioning allocates all the space required for the virtual disk upfront and marks all the space as zeroed. This means that the physical space is reserved and zeroed on the storage array, ensuring that the VM does not have to wait for space to be allocated or zeroed before writing data. This can lead to better performance, especially for I/O-intensive applications1.

XtremIO and EZT: XtremIO arrays are particularly well-suited for EZT because they use inline deduplication and never actually have to zero out physical media. The metadata is kept in memory, and writes are journaled to memory before being saved to SSDs. XtremIO uses VAAI (vStorage APIs for Array Integration) to accelerate zeroing operations, so hosts do not have to write zeros, and the allocation of EZT virtual disks is a very quick operation1.

Performance Considerations: For applications that require low latency, such as databases, using EZT reduces overall latency for the application. Since XtremIO arrays are designed to handle such operations efficiently, the initial zeroing process with EZT, which could take a long time on traditional storage architectures, is significantly faster1.

In conclusion, for ensuring proper performance and capacity usage for a VM on vSphere 6.5 with an XtremIO volume, Thick Provisioned, Eager Zero is the recommended method of disk presentation.

According to the Dell Technologies community forum and support articles, the show-clusters-info command in the XtremIO Management Server (XMS) CLI provides information about the clusters. For a healthy XtremIO cluster, the state should be displayed as active and connected1. This indicates that the cluster is operational (active) and has a stable connection with the necessary components and network (connected). It's important to ensure that the cluster state does not show as disconnected, which could imply issues with network connectivity or other problems affecting the cluster's operation2.

The largest size supported for each volume in a new XtremIO X2-S single X-Brick cluster, as per the Official Dell XtremIO Deploy Achievement documents, is 64 TB. This information is verified through the official documentation which outlines the capabilities and specifications of the XtremIO X2 systems. The documents provide a detailed description of the critical components, features, and implementation solutions in customer environments, which includes the storage capacity specifications for XtremIO systems1.

For a four X-Brick XtremIO X1 cluster, the total number of Power Distribution Panels (PDPs) that need to be connected to an electrical source is eight. This is based on the standard configuration for a four X-Brick cluster, which typically includes two power supplies per X-Brick and additional power supplies for the InfiniBand switches and other components1.

The process for connecting PDPs involves:

Identifying Power Requirements: Determine the power requirements for each component of the XtremIO X1 cluster, including X-Bricks and InfiniBand switches.

Allocating PDPs: Allocate the necessary number of PDPs based on the power requirements identified.

Connecting to Electrical Source: Connect each PDP to the electrical source, ensuring that the power distribution is balanced and meets the cluster's needs.

Verifying Power Supply: After connecting, verify that all components are receiving adequate power for operation.

Ensuring Redundancy: Ensure that there is redundancy in the power supply to protect against failures.
